12 volt DC/DC Converter (10V to 20V input) with screw terminals

12V regulated DC converter with 10-20VDC input

Wide input range 12 volt to 12 volt DC/DC converter

These are regulated switching power converters, designed to allow the use of equipment that requires a regulated 12 volts in 12 volt battery systems and vehicles. The packaging is a circuit board with a sealed DC converter brick with associated connectors.

To determine the amperage you would need add up the watts of all the equipment and divide by 12 volts.

PST-DC2012 50W 12V to 12V regulator	$96
PST-DC2012-1Z 25W 12V to 12V regulator	Not stocked at this time, sorry

>	>4.2 Amp Peak DC to DC Converter
>Part Number	PST-DC2012
>Input Voltage	10 to 20 VDC
>Output Voltage	12VDC
>Output Voltage Range	(optional) 10.8VDC to 13.2VDC trimmed by resistors
>Setpoint Accuracy	±1%
>Line and Load regulation	±0.2%
>Max Output Current(s)	4.2 A
>Max Output Power	50Watts
>Trim	Trim range is ±10% with user-supplied trim resistors Consult this manual for trim instructions
>Connectivity	Input: Screw terminals Output: Screw terminals On/Off control: Screw terminals
>Isolation	Fully isolated to 3000 volts between input and output
>Efficiency	Better than 90%
>Remote power on/off?	Yes, Ground On/Off terminal to turn off
>Protection	Short circuit, over temperature, overload, reverse input
>	107mm x76mm x 23mm (4.2 x 3.0 x .9 inches)
>Mounting	holes are 0.150" in diameter (3.8mm) 2.5" on center (63.5mm) and 3.75" (95mm) on center
>Weight	4 oz, 110 g
>Agency approvals	UL component, cUL component TUV

Advantages:

Inexpensive High Current Switchmode DC/DC Converter.

High efficiency >90%.

Wide input voltage range, 10V to 20V.
